钎焊、退火、溶解淬火连续式炉 Continuous Conveyor Belt Furnace for Brazing, Annealing and Solution Quenching

加热方式 电加热 (热风循环)燃气加热
优点 均温度优良(±5℃)在加热室能自动控温和显示氧含量可依客户需求,提供炉内不同的充入气体和环境特殊保温节省能源消耗提供高纯度的气体环境,并减少气体消耗所有工件在炉内收到均匀的热度,增加产品的均匀性能有效完成钎焊,无需再处理
使用于 钎焊退火溶解淬火硬化(能单独硬化的合金)
型号 尺寸(mm) (W×L×H) 温度范围(℃)
EF-01 500×500×500 980
EF-02 800×800×800 100~1200
EF-03 1000×1000×1000 100~1200
EF-04 1500×1500×1500 100~1200
EF-05 2000×2000×2000 100~1200
EF-C 依照需求客制化尺寸 100~1200
Heating Method Electric Heating (convection)Gas Heating
Advantage Temperature Uniformity(±5℃)Automatic temperature control and oxygen content in the chamberAccommodate reactive or insert gas atmospheres upon customer’s requestEnergy efficient design insulationUltra-pure atmospheric environment with minimal gas consumptionAll treated components undergo the same temperature gradients through the furnace therefore increase product uniformityCan complete a clean sintering treatment without reprocess
Application BrazingAnnealingSolution heat-treatmentHardening (for self-hardening alloys)

其它說明:
